I believe i need to replace my thermostat but i can not find a diagram showing me where it is. my car is driving warm but not over heating and the fluids are fine. it is throwing a code saying air flow problem. i need help fixing my car so i can get my new yearly sticker.
2002 Saturn L100
This is the 4 cylinder engine:
On the 6 cylinder engine, it requires the removal of the intake to access the thermostat housing.
