2004 Hyundai Sonata 2.4lDecember 8, 2015 I am stuck trying to do the timing belt and the crankshaft position sensor can you assist me on the proper steps. Share Tweet Pinterest Keywords:Sonatatiming belt 1 thought on “2004 Hyundai Sonata 2.4l” FreeAutoMechanic December 8, 2015 at 11:54 am The crankshaft position sensor is located just above the crank shaft, refer to the diagram below. There is one electrical connection and a couple of bolts. Not much to replacing the sensor once you have removed everything else out of the way. To save some time here is the the complete timing belt replacement manual that covers the 2.4L, 2.5L and 2.7L engines. 2004 Hyundai Sonata timing belt replacement manual Comments are closed.
