Sep 052018


1962 Lincoln Continental

Single click and nothing else

I have a 1962 Lincoln Continental hardtop with a 430. It was running fine until a week ago. Suddenly, out of nowhere, when you turn on the ignition, there’s a single click and nothing else. This click is coming from the external starter motor relay. I replaced the relay and I’m getting exactly the same thing. The battery is brand new and fully charged. When I turn the ignition switch, the voltage across the battery terminals drops to 12.05. So it can’t be the battery. There’s a 0.07 volt drop between the positive battery terminal and the post on the starter regardless of whether the ignition switch is turned or not. There’s a 0.00 volt drop (so no drop at all) between the negative post of the battery and the starter motor housing when the ignition is off and a 0.03 volt drop when the ignition is engaged. So if my understanding is correct, there’s no significant voltage drop. Is the starter motor broken?


Replacing the Starter motor would be the fix. This is of course after you confirm the wiring is good from the Starter solenoid to the Starter along with the connections.

Starter Motor Brush Replacement

  1. Remove the starter from the engine.
  2. Remove the starter drive plunger lever cover and gasket.
  3. Loosen and remove the brush cover band and remove the brushes from their holder.
  4. Remove the two through-bolts from the starter frame.
  5. Separate the drive end housing, starter frame and brush end plate assemblies.
  6. Remove the starter drive plunger lever and pivot pin, and remove the armature.
  7. Remove the ground brush retaining screws from the frame and remove the brushes.
  8. Cut the insulated brush leads from the field coils, as close to the field connection point as possible.
  9. Clean and inspect the starter motor.
  10. Replace the brush end plate if the insulator between the field brush holder and the end plate is cracked or broken.
  11. Position the new insulated field brush leads on the field coil connection. Position and crimp the clip provided with the brushes to hold the brush leads to the connection. Solder the lead, clip, and connection together using resin core solder. Use a 300 watt soldering iron.
  12. Install the ground brush leads to the frame with the retaining screws.
  13. Install the starter drive plunger lever and pivot pin, and install the armature.
  14. Assemble the drive end housing, starter frame and brush end plate assemblies.
  15. Install the two through-bolts in the starter frame. Tighten the through-bolts to 55-75 inch lbs. (6.2-8.5 Nm).
  16. Install the brushes in their holders and install the brush cover band.
  17. Install the starter drive plunger lever cover and gasket.
  18. Install the starter on the engine as previously outlined.
Aug 272018


Lincoln Towncar

The check engine light is on solid. The code P0183 which is the” fuel temperature sensor” is not happy. I have two questions about this code, where is this sensor located and what is the part number of the sensor.
I have called eight parts store and four Lincoln/ford dealers trying to get these two questions answered and got no ware. Please help me if you can to solve this baffling problem.

It is very strange that even dealers cant come up with answers. Is it possible that something else is triggering this code and it is not the fuel temperature sensor at all.

Thanks for any help you can give me.
PS: The car starts and runs just fine. 2005 Lincoln Town Car Signature series


Fuel Temperature Sensor

I went ahead and looked up the part for you. I double checked to make certain this is an exact fit for your 2005 Lincoln Town Car Signature series.

Shop Automotive

Fuel Temperature Sensor Location

The fuel temperature sensor is located on the fuel rail. It is the same sensor as the fuel pressure sensor. One vacuum line, 2 screws and one electrical plug.

fuel temperature sensor

Item Part Number Description
1 14A464 Fuel rail pressure and temperature sensor electrical connector
2 9E498 Fuel rail pressure and temperature sensor vacuum connector
3 N808874 Fuel rail pressure and temperature sensor bolts (2 required)
4 9F972 Fuel rail pressure and temperature sensor
5 Fuel rail pressure and temperature sensor O-ring

Code P0183 – Fuel Temperature Sensor A Circuit High Input

Probable Causes:

  1. Sensor or solenoid faulty
  2. Connector terminal contact is damaged or corroded
  3. Wire harness – Check harness for correct voltage, open, short to ground or short to voltage
  4. Update control unit software – Check for the latest control unit update
  5. Powertrain or Engine Control Module faulty
Aug 222018


Lincoln Towncar

repair or replace motor?


Drivers seat that wont go up or down

First determine if the motor is getting power from the switch. And if not, is the switch getting power. If you find the switch operating as it should and power getting to the motor, it may need to be replaced. Next, check all connections and test motor with both battery positive and negative.

The up and down function wires coming from the switch are RED/LT GREEN and YELLOW/LT GREEN. The black wire on the switch is connected to battery negative(ground). Use the wiring diagram provided to get an idea of how the circuit works.

Drivers Side Seat Circuit Wiring Diagram

2010-lincoln-town-car-color-schematics-seats-driver-power-seat-circuit-1-of-1-
Mar 142018


2012 Lincoln MKT

How to replace radiator?


Radiator Replacement Procedure – 2012 Lincoln MKT 3.7L
2012-lincoln-mkt-radiator

Removal and Installation

  1. Drain the cooling system.
  2. Remove the cooling fan motor and shroud.
  3. Remove the front bumper cover.
  4. Disconnect the upper radiator hose and lower degas bottle hose from the radiator.
  5. Disconnect the lower radiator hose from the radiator.
  6. NOTE: LH shown, RH similar.

Lift the tabs and remove the radiator support brackets and position the radiator toward the engine.

radiator tabs diagram
7.Remove the 2 A/C condenser bolts from the radiator and separate the condenser from the radiator. •To install, tighten to 6 Nm (53 lb-in).
8. NOTE: Make sure the bottom radiator insulators are in place when installing the radiator.
Remove the radiator.
9.To install, reverse the removal procedure.
10.Fill and bleed the cooling system.

Dec 012017


2003 Lincoln Town Car

I have a 2003 Lincoln Town Car Signature Premium. Great shape, low miles, excellent condition. Everything worked perfectly until yesterday! I noticed the battery terminals were corroded so I cleaned them. After I put them back on NOW the drivers side seat controls do not work, the mirror controls do not work, the air suspension light on the dash stays on and the power steering is barely working. I have checked ALL fuses (interior and exterior), checked the connections beneath the seat, the power steering fluid is full. I have disconnected the battery to let the modules reset…still nothing works. Any ideas?


Problems after cleaning battery terminals

Like you said, it was fine until you touched it. You cleaned the battery terminals which was the right thing to do. I would guess somehow some wiring got touched where it wasn’t supposed to or caused a brittle wire to break. But lets look at the wiring diagrams (provided below)of each circuit and see if we can find a connection.

Taking a quick look I can see the power mirrors and drivers power seat both share the same GROUND connection, G207. And looking at the electronic suspension and electronic power steering I can see they share the same TWO FUSES, number 8 and 10. You might want to double check those fuses not only to see if they are good, but that they have power going to them. Then check the ground connections for the rest.  If the corrosion was bad enough, there might be some additional corrosion in the battery cables themselves. If so, replacing the cables would be the next move.

  • mirror fuses 18, 30 ground G207
  • seat fuse 108 ground G207
  • electronic suspension fuses 8,10,114 and Electronic power steering connected from Air Suspension Module Pin 26 (LT GRN/BLK wire)- grounds G102 and G405
  • electronic power steering fuses 8, 10 ground G201

(DIAGRAMS BEST VIEWED IN GOOGLE CHROME OR FIREFOX)

Power Mirrors with electronic day/night mirror wiring diagram

2003-lincoln-town-car-mirrors-power-mirrors-circuit-w-electronic-day-night-mirror-1-of-1

Drivers power seat circuit wiring diagram

2003-lincoln-town-car-seats-driver-power-seat-circuit-1-of-1

Electronic suspension wiring diagram

2003-lincoln-town-car-electronic-suspension-1-of-1

Electronic power steering wiring diagram

2003-lincoln-town-car-electronic-power-steering-1-of-1
Sep 252017


2011 Lincoln MKS

Does the speaker cover on the passenger front door come off without having to remove the door panel ? It is dented in and I just want to pop it back to shape. thank you


The speaker cover is part of the door panel. Removal of the door panel will be required.

Door panel removal 2011 Lincoln MKS

2011-lincoln-mks-door-trim-panel-front-removal-and-installation

Removal and Installation

All trim panels
1.Pull outward and remove the sail panel. •If equipped, disconnect the electrical connector.

2.Remove the front door inside handle assembly bolt cover.
3.Remove the front door inside door handle assembly bolt. •To install, tighten to 7 Nm (62 lb-in).

4.Remove the front door trim panel center bolt. •To install, tighten to 7 Nm (62 lb-in).

5.Remove the trim panel grommet and remove the front door trim panel rear screw. •To install, tighten to 1 Nm (9 lb-in).

6.Remove the front door trim panel lower screws.

7. NOTICE: Avoid pulling directly on the upper rear corner (vinyl portion) of the door trim panel during removal to prevent damage to the door trim panel.
Remove the front door trim panel. •Pull the front door trim panel outward to release the retaining clips.
•Disconnect the inside door handle cable.
•If equipped, disconnect the electrical connectors.
Window garnish moulding
8.Remove the window garnish moulding screw.
9.Remove the window garnish moulding.

All trim panels

10. NOTICE: To avoid damage to the door trim panel, remove any retaining clips from the body and attach them to the door trim panel.
To install, reverse the removal procedure.

Rear Wiper Motor 2000 Lincoln Navigator

 Auto Repair Questions, Lincoln  Comments Off on Rear Wiper Motor 2000 Lincoln Navigator
Aug 242017


2000 Lincoln Navigator

Rear wiper comes on

Something keeps draining my battery. Also the rear wiper comes on every now and then without being turned on. If you suspect I need a rear wiper motor, can you tell me where to find a diagram and instructions.


Wipers And Washers—Rear Window

The rear window wiper and washer system consists of the following:

  • rear window washer nozzle and jet
  • a rear window wiper arm and blade
  • rear window wiper motor
  • multifunction switch

Rear wiper motor wiring diagram

2000-lincoln-navigator-wiper-washer-rear-washer-wiper-circuit-1-of-1

Rear wiper motor replacement

2000-lincoln-navigator-motor-8212-rear-wiper-removal-and-installation
Feb 242017


2008 Lincoln TowncarI HAVE A HARD SHIMMY IN RIGHT FRONT WHEN I HIT A CHUGHOLE AT 65 OR MORE MPH


RESPONSE

About the only thing to do would be to inspect it. Put the front end up on jack stands and start looking. Look for loose mountings and or play in the joints.

Most common if it was not there until you hit the chughole would be a busted belt in the tire. You can rotate the tire tot he back and see if it changes. Replacing the tire would be the correct measure to take.

Feb 192017


 Lincoln Town CarHello, i’ll get right too it. My car has been parked for months now.

And i tried starting it but the battery died on me, “it’s winter here” so i traded it for a fresh one, now, the engine cranks normal “even with remote” but wont start.

The last time i started it, it had snowed quite a bit to the point snow was flush with my under carriage and Starter of coarse and maybe up inside the engine bay.

So I have no interior lights. I had cleaned the post and connectors.

All is done right, i’m thinking the Switch or bad Ground, wire. On account of the snow being so close to the wires.

So, it cranks but wont start and no lights “Interior/but one light i barely saw was in the Dash” and that was Service Engine Soon.

That S.E.S. was for my Gas cap i replaced and forgot to erase.

and it cranks with remote… but no Door Locks work or anything else on the Remote.

What you thinking

Thank You in Advance


RESPONSE

After a car sits for a awhile it may need to have the fuel system primed. This can be done by cycling the key. Turn the key to “ON” and hold for 5 seconds and then turn the key to “OFF”. Repeat 10 to 15 times. This will prime the fuel system.   A quick test would be to spray starting fluid in the air filter and see if it wants to start. Could be out of gas or a few other things. I have created a wonderful No Start Diagnostic Chart for just an occasion. Follow the steps on the chart.

Lack of interior lights could be a blown fuse or a bad connection at the battery. Make sure you connected all the wires that were removed when replacing the battery.
