2010 Subaru Impreza Hatch RS Manual Steering Column

 Auto Repair Questions, Subaru  No Responses »
Mar 262020


2010 Subaru Impreza

I was fidding with the steering to get my heater core out and i accidently popped out the bushing that the steering colum goes through thats at the firewall, how should i apprach getting it back in or is this a job for an actual mechanic

Give it a try yourself. And you are still left with the option to take it to a mechanic.

Steering Column Installation Video

Tilt Steering Column Removal

  1. Remove the steering wheel as follows:
    • Disconnect the ground cable from battery.
    • Set the tire to the straight-ahead position.
    • Remove the airbag module as outlined in the Chassis Electrical Section.
      WARNING

      Always refer to “Airbag System” before performingservice on the airbag modules as outlined in the Chassis Electrical Section.
    • Place alignment marks on the steering wheeland steering shaft.
    • Remove the steering wheel nut, and then drawout the steering wheel from shaft using steeringpuller.
  2. Remove the universal joint as follows:
    • Remove the steering wheel as outlined above.
    • Place alignment marks on universal joint.
    • Remove the universal joint bolt and remove theuniversal joint.
  3. Remove the instrument panel lower cover under.
  4. Remove the instrument panel lower cover upper.
  5. Remove all connectors from the steering column.
  6. Remove the two bolts under instrument panelsecuring the steering column.
  7. Pull out the steering shaft assembly from thehole on toe board.
    CAUTION
    • Be sure to remove the universal joint beforeremoving steering shaft assembly installingbolts when removing steering shaft assemblyor when lowering it for servicing other parts.
    • Do not loosen the tilt lever when the steeringcolumn is not secured to the vehicle.
      2010-subaru-impreza-steering-column

To install:

  1. Install the grommet to the toe board.
  2. Insert the end of the steering shaft into the toeboard grommet.
  3. With the tilt lever secured, tighten the steeringshaft mounting bolts under instrument panel. Tighten bolts to 18 ft. lbs. (25 Nm)
  4. Connect all the connectors under the instrumentpanel.
  5. Connect the airbag system connector at the harnessspool.
    NOTE

    Make sure to apply double lock.
  6. Install the instrument panel lower cover with tiltlever held in the lowered position.
  7. Install the universal joint as follows:
    • Align the cutout portion at serrated section of thecolumn shaft and yoke, then install the universaljoint into column shaft.
    • Install the universal joint to the serrations ofgearbox assembly by matching alignment marks.
    • Tighten the bolts to 18 ft. lbs. (24 Nm)
      CAUTION

      Excessively large tightening torque of universaljoint bolts may lead to heavy steering wheeloperation. Clearance between coupling of universal jointand turbo cover: 0.59 inch (15 mm) or more.
    • Align the center position of the roll connector as follows:
      • Check that front wheels are positioned in straightahead direction.
      • Turn the roll connector pin clockwise until itstops.
      • Turn the roll connector pins approx. 3.25turns in the counterclockwise direction until “ ”marks are aligned.
    • Install the steering wheel as outlined below.
  8. Install the steering wheel as follows:
    WARNING

    Always refer to “Airbag System” before performingservice on the airbag modules as outlined in the Chassis Electrical Section.
    • Align the center position of the roll connector as outlined above.
    • Install the airbag module as outlined in the Chassis Electrical Section.
    • Set the tire to the straight-ahead position.
    • Connect the ground cable from battery.
      WARNING

      Always refer to “Airbag System” before performingservice on the airbag modules as outlined in the Chassis Electrical Section.
    • Align marks placed on the steering wheeland steering shaft before removal.
    • Install the steering wheel to the shaft using steering puller, and then install the nut.
      NOTE

      Align the alignment marks on the steering wheeland steering shaft.
    • Tighten bolts to 29 ft. lbs. (39 Nm). Column cover-to-steering wheel clearance:0.08–0.16 in (2–4 mm)
      CAUTION

      Insert the roll connector guide pin into theguide hole on the lower end of the steeringwheel surface. Avoid damaging the pin.

High Output Alternator 2013 Subaru Legacy 2.5i 4cyl

 Auto Repair Questions, Subaru  Comments Off on High Output Alternator 2013 Subaru Legacy 2.5i 4cyl
Jan 032020


2013-subaru-legacy

cant find any higher output alternators that look like they fit the mount. do they even make them or will i have to have one built?

There doesn’t seem to be a factory fit high performance alternator that will fit the factory mounts. There are a couple options for this. Purchase an Overdrive pulley and see if it takes care of your needed power supply issues. The factory out put is 110 amps. The Overdrive pulley sold by Carid advertises 50% increase.

overdrive-pulley

They also sell a high output performance alternator that claims up to 300% more charging power but no mention of amps. And this may require using a different mounting system or fabricating one.

mean-grteen-alternator

Maperformance offers an aftermarket alternator mounting bracket but carries a hefty price tag.

aftermarket-alternator-mounting-bracket

Front Brake Pad Replacement 2014 Subaru Crosstrek

 Auto Repair Questions, Subaru  Comments Off on Front Brake Pad Replacement 2014 Subaru Crosstrek
Oct 082019


2014-subaru-crosstrek

My rotors, brakes or calipers are making this very high pitched noise but only have some time of driving, with the turn of the wheel, even just a little and after hitting bumps… it stops when i hit the brakes. I have a video of the noise if theres a way to share that

Generally if the noise stops when the brake pedal is applied it means you need to have the brakes serviced. Simple put, you need the brake pads replaced at a minimum. I recommend replacing the rotors at the same time you have the brake pads replaced.

Brake Pads, Replace

Front

Removal

Do not disconnect brake hose from caliper body assembly.

1. Raise and support vehicle and then remove front wheels.

2. Remove caliper bolt on lower side.

3. Raise caliper body assembly and support it, see image.

4. Remove brake pads from caliper bracket, see image.

2014-subaru-crosstrek-brake-pad-removal

Installation

Ensure to install so that pad return spring faces input side of direction of brake rotor rotation.

Correctly install pad return spring to supporting surface of pad retainer.

If pad return spring is deformed or damaged, replace brake pad with a new component.

Before installation, remove mud and foreign matter from caliper body assembly and support.

Install brake pad indicator in proper direction.

1. Inspect brake pad.

2. Apply a thin coat of grease to pad retainer, see image.

3. Apply a thin coat of grease to pad and both sides of shim, disc brake front inner (a), see image.

2014-subaru-crosstrek-brake-pad-instalation

4. Install brake pad to bracket.

5. Install caliper body assembly to support. Torque caliper bolt to 20 ft. lbs.

6. Install front wheel and tire assemblies. Torque wheel nuts; except for C4 model to 89 ft. lbs. and C4 model to 74 ft. lbs.

Inspection

Wear indicators are installed on inner and outer disc brake pads.

If pad is worn to limit, end of wear indicator contacts disc rotor and a squeaking sound is heard as wheel rotates. If sound is heard, replace pad.

Always replace pads of both wheels and both sides as a set.

Replace pad retainers if they are twisted or worn.

Replace pad if there is oil or grease on it.

1. Inspect pad thickness. Standard .43 inch, Wear limit .059 inch.

2. If wear limit is exceeded in inspection, replace brake pad.

Fans not coming on 2012 Subaru Outback 4 cylinder

 Auto Repair Questions, Subaru  Comments Off on Fans not coming on 2012 Subaru Outback 4 cylinder
Apr 102019


2012-subaru-outback

My car smells like its overheating but not steaming. Fans are not coming on. tested it last night and after about 30 min of running and reving it up, it blew a little steam out radiator cap. I am not getting warning lights on the dash at all. I tested all fuses and relays to the fans. could it be thermostat? why would fans not work?

First you may want to use an external infrared thermometer. Aim it at the engine block and check the temperature. This will prove if the engine is overheating or not. If the engine is not warm enough the fan will not come on.

Fans not coming on

The Engine cooling fan is controlled by the ECM. The ECM uses an Engine Coolant Temperature Sensor signal to decide when to turn the fan on and off. I the coolant level is low the sensor will not be able to read the correct temperature. So first thing to do would be to check the coolant level. If the coolant level is low, find out why and make the necessary repairs.

Subaru Code P0037 Oxygen Sensor

 Auto Repair Questions, Subaru  Comments Off on Subaru Code P0037 Oxygen Sensor
Mar 192019


Subaru Outback

I replaced my converters and the oxygen sensor but my check engine light is still on. I took it and the code was P0037 bank 1, sensor 2 low voltage ? It is a 2003 Subaru Outback with 2.5.

Subaru Code P0037

– HO2S Heater Control Circuit Low Bank 1 Sensor 2

How to Diagnose Code P0037

2003-subaru-outback-code-p0037

Head gasket replacement 2001 Subaru Outback Wagon

 Auto Repair Questions, Subaru  Comments Off on Head gasket replacement 2001 Subaru Outback Wagon
Nov 302018


Do I need to remove the engine to replace the left hand head gasket?

No. Does not require engine removal.

Head Gasket Replacement Labor Time

2.5L Engine

  • one side only = 6.5 hours
  • both sides = 10.2 hours

3.0L Engine

  • one side only = 11.9 hours
  • both side = 12.8 hours

2001 Subaru outback makes a ticking noise

 Auto Repair Questions, Subaru  Comments Off on 2001 Subaru outback makes a ticking noise
Feb 102018


2001 Subaru Outback

Changed my oil Wednesday and transmission. Car was running not that great before hand. Filled up oil with 10w30 synthetic and added a bottle of Lucas oil stabilizer. (I always use to add 10w30). Filled transmission with DEX3 5 quarts. (Over filled it by a quart) ever since I changed fluids when I start the car it makes a ticking noise. Once it warms up it gets lower.

2001 Subaru outback makes a ticking noise

White Smoke Subaru Forester 2001 GT turbo, automatic

 Auto Repair Questions, Subaru  Comments Off on White Smoke Subaru Forester 2001 GT turbo, automatic
Feb 092017


2001 Subaru ForesterSo, one day I went to check my oil and coolant and they were both low. So I used a different car to go get the products to top them up, using both permite (that’s what last owner used) but I wasn’t sure what oil they used. There was 5-30 but there was also 5-40 which recommended using if i was putting 5-30 in it. So I put the 5-40 one in anyways that’s not the point of the story.

The point is afterwards I went to the petrol station to get some fuel and as I was stopped at the lights on my way out white smoke just came out of my exhaust. As soon as the light turned green I took off and parked to see what was going on, and it stopped? But now every time I drive my car and stop at a red light or something it smokes. At first not so much but as I’m sitting there idling it gets worse. It does stop after I’ve stopped like 4 times (for example on my way back from the shops I stopped my car in the driveway to see the smoke and it didn’t smoke at all…its soo weird, suggestions?

RESPONSE

White Smoke

White smoke is an indication of a engine coolant being burned in the engine. This can be caused by a blown head gasket or leaking intake manifold gasket.

Blue Smoke

Blue smoke is created by the vehicles engine oil entering a cylinder and being burned along with the Air/Fuel mixture. A small amount of oil leaking into a cylinder will create blue smoke out the tailpipe. Blue smoke is more often and issue in older or higher mileage vehicles.

Sometimes using a thicker oil can help, but in most cases replacing the failed gaskets and seals is the best way to insure the issue is fixed.

Black Smoke

Vehicles before 1996 will sometimes emit black exhaust smoke during the first start up of the day, this is normal as long as it clears up once warm. On vehicles built after 1996 , Black exhaust smoke is not normal. This is an indication that the engine is not burning the fuel efficiently and or the fuel injection system is trying to force to much fuel through the engine.
Possible causes range from a failed O2 Sensor, Injector Stuck open, or failing MAF Sensor. Some times a simple tune up is all that is needed.

Brake Fluid Sealer 1993 Subaru Legacy wagon

 Auto Repair Questions, Subaru  Comments Off on Brake Fluid Sealer 1993 Subaru Legacy wagon
Dec 122016


1993 Subaru LegacyCan I put some kind of brake fluid sealer to stop it from leaking?

RESPONSE

Brake Fluid Sealer

My response is NO. The brake system utilizes extreme pressures to operate. The brake fluid leak needs to be properly repaired in order for the system to function correctly. The basic principle of a brake system is the free movement of fluid through the brake lines. Any kind of brake fluid sealer would ruin the entire system and cause more damage.

How to locate a brake fluid leak

First of all park on a flat clean surface or place clean cardboard under the vehicle.Top off the brake fluid reservoir. Pump the brake pedal a few times while someone looks under the car. Hence you may notice a hissing noise. This is the fluid escaping. Look on the ground and note a puddle. If none are found maybe look at the insides of your tires. Finally this will give you an idea of the location of the leak. In conclusion brake fluid leaks are generally affordable to fix.

Turbo on 2002 Subaru Forester XT

 Auto Repair Questions, Subaru  Comments Off on Turbo on 2002 Subaru Forester XT
May 232016


2002 Subaru ForesterMy Subaru’s turbo is only active in colder weather. I live in Southern Africa where it rarely gets very cold. This car has been imported from Japan. The highest octane fuel we can get here is 95 octane. Can anybody help me with some idea where to start looking for the problem?

RESPONSE

No Recalls or Technical Service Bulletins were found when searching for Turbo related issues.

That is odd since the turbo works off the exhaust system. The Turbocharger may be going out.

Turbo Charger Replacement

Removal & Installation

  1. Before servicing the vehicle.
  2. Disconnect the negative battery cable.
  3. Remove the center exhaust pipe.
  4. Separate the turbocharger joint pipe from the turbocharger.
  5. Disconnect the engine coolant hose from the coolant filler tank.
  6. Loosen the clamp that attaches the turbocharger to the intake duct.
  7. Remove the oil pipe-to-turbocharger bolt and remove the oil pipe from the turbocharger.
  8. Remove the turbocharger bracket and disconnect the oil outlet hose from the pipe.
  9. Remove the turbocharger.

To install:

  1. Installation is the reverse of removal, please note the following torque specs:
    1. Turbocharger-to-intake duct: 2 ft. lbs. (2 Nm).
    2. Oil pipe-to-turbocharger: 11 ft. lbs. (16 Nm).
    3. Joint pipe-to-turbocharger using a new gasket: 22 ft. lbs. (30 Nm).
    4. Turbocharger bracket: 24 ft. lbs. (33 Nm).
