Mar 142020


1997-toyota-rav4

Vehicle was running fine.
One day, wife turns on headlamps and horn starts blaring.
Shuts lights off, horn stops.
This is consistent and repeatable.
Went to start it next day and battery is completely dead.
Hooked up jumper cables and got lots of sparks.
Let it charge up a minute and had her turn the key.
Rav started right up.
As soon as I removed jumper cables, the Rav died.
I re-connected cables (again lots of sparks) and the engine started cranking itself – without the key inserted.
Again, this is consistent and repeatable.
There are no blown fuses and the relays seem fine, but I haven’t replaced any.

I have access to an automotive probe and a basic understanding of automotive electrical, but don’t know where to start in this case.



Sounds like the starter relay/solenoid is sticking a bit. Also the Battery is not being charged. The alternator is not charging the battery and or the battery itself is no longer able to take a charge. That is why the engine dies as soon as the jumper cables were removed.

If the battery is around 4 years old or older it would be a good idea to replace it anyway. Once the battery is replaced then you can perform further testing.

You can tap on the starter relay/solenoid with the end of a screw driver and it may cause it to release.

Check all fuses and Fusible links. Here is a wiring diagram for reference.

1997 Toyota Rav4 Charging System Wiring Diagram

1997-toyota-rav4-charging-wiring-diagram

Feb 062020


1997-toyota-rav4

I have retrieved code 44 from OD flashlight, which points to an issue with the “transmission rear output shaft speed sensor”. The car has A540H transmission. Where is this speed sensor located? How many speed sensors does this transmission have?



This vehicle has two Speed Sensors. The Front Speed Sensor and the Rear Speed Sensor. The No. 1 Vehicle Speed Sensor is located on top of the transaxle. The No. 2 Speed Sensor is Located at the rear of the transaxle.

The front speed sensor detects vehicle speed based on ring gear RPM. The Rear speed sensor detects rear wheel speed based on transfer drive gear RPM. I have provided testing procedures for both sensors.

1997-toyota-RAV4-rear-speed-sensor-location-diagram

Testing the No. 1 Vehicle Speed Sensor (VSS)

1997-toyota-rav4-vss-location-diagram

  1. Disconnect electrical connector from No. 1 VSS, located on top of the transaxle. See Figure. Connect positive battery lead to terminal No. 1 and negative to terminal No. 2. Connect positive lead of voltmeter to terminal No. 3 and negative to terminal No. 2. See Fig 1.
  2. Raise and support one vehicle front wheel. Rotate wheel and monitor voltmeter. Ensure voltage changes from zero to 11 volts. Voltage should change 4 times per each revolution of speed sensor shaft. Replace speed sensor if voltage does not change as specified.

1997-toyota-rav4-vss-test-diagram

Testing the No. 2 Vehicle Speed Sensor (VSS)

  1. Ensure ignition is off. Access ECT ECU. See Figure Above for location. Backprobing ECT ECU harness connector with ohmmeter, measure resistance between terminal RR+ and terminal RR-. See Figure below. Resistance should be 560-680 ohms. If resistance is within specification, replace ECT ECU. If resistance is not within specification, go to next step.
  2. Remove rear speed sensor from transaxle. Measure resistance between sensor terminals. Resistance should be 560-680 ohms. If resistance is not specified, replace sensor. If resistance is specified, check and repair circuits between sensor and ECT ECU.
  3. Check voltage between sensor terminals when a magnet is put close to tip of sensor. If a low intermittent voltage is generated, sensor is okay. If no voltage is generated, replace speed sensor.

1997-toyota-rav4-ect-ecu-connector-pin-out

Toyota Code 44 – Deceleration Sensor Circuit

Code 44 Description

This sensor detects deceleration on the vehicle. The sensor signal is used in ABS control. If the sensor functions abnormally, the ABS warning light comes on but still operates.

toyota-code-44-list-1

toyota-code-44-wiring-diagram

toyota-code-44-inspection-1

toyota-code-44-inspection-2

toyota-code-44-inspection-3

How to scan SRS Codes without a Scan Tool

 Auto Repair Questions, Toyota  Comments Off on How to scan SRS Codes without a Scan Tool
Jan 312020


2012 Toyota Camry

I bought a 2012 Toyota Camry ELE repaired after a collision. The SRS light stays on. I have safely unplugged and checked the SRS connection under the passenger seat. I sent the SRS ECU to be reset and then re-installed it. The SRS light is still on. There are no OBD2 codes. What to do next?



If you have a scan tool you may connect it and pull the codes or do it without a scan tool. I have provided the procedures below for both scanning and clearing the present codes. I have also provided a list of corresponding diagnostic trouble codes.  Then check wiring and sensors that correspond to the present code or fault. These codes would begin with a B.

Scan Codes without a Scan Tool

  1. Turn ignition switch to Acc or On position.
  2. Wait approximately 20 seconds.
  3. Connect DLC terminal Tc and E1 or Tc and CG with special diagnosis check wire tool No. 09843-18020 or equivalent jumper wire.
  4. Read two-digit DTC from SRS warning lamp as blinks as follows:
    a. If lamp flashes two times per second, there are no DTCs stored.
    b. If a fault code is indicated, first digit will flash, then after 1.5 seconds elapse, second digit will flash.
    c. If more than one code is stored, 2.5 seconds will elapse, then second code will appear.
    d. DTC flashes will be displayed from smallest numerically to largest.
    e. After all stored DTCs have been read, 4.0 seconds will elapse and DTCs will be repeated.
Clearing Diagnostic Trouble Codes without a Scan Tool
  1. Connect two special diagnosis check wire tools No. 09843-18020 or equivalent jumper wires, to DLC terminals Tc and AB or Tc and CG.
  2. Turn ignition switch to Acc or On position and wait approximately six seconds.
  3. Alternately ground each jumper wire twice in one second cycles as follows:
    a. Ground Tc jumper for .5-1.5 second.
    b. Release Tc ground and immediately ground AB jumper within .2 second.
    c. Ground AB jumper for .5-1.5 second.
    d. Release AB ground and immediately ground Tc jumper within .2 second.
    e. Ground Tc jumper for .5-1.5 second.
    f. Release Tc ground and immediately ground AB jumper within .2 second.
    g. Ground AB jumper for .5-1.5 second.
    h. Release AB ground and immediately ground Tc jumper within .2 second.
  4.  Ground Tc jumper.
  5. SRS warning lamp will blink in a 50 milli-second cycle several seconds after clearing procedure is completed to indicate DTCs have been cleared.

Toyota Diagnostic Trouble Codes Interpretation

Code Description
Scan Tool SRS Lamp
B0100 13 Short In D Squib Circuit
B0101 14 Open In D Squib Circuit
B0102 11 Short To Ground In D Squib Circuit
B0103 12 Short To B+ In D Squib Circuit
B0105 53 Short In P Squib Circuit
B0106 54 Open In P Squib Circuit
B0107 51 Short To Ground In P Squib Circuit
B0108 52 Short To B+ In P Squib Circuit
B0110 43 Short In Side Squib Righthand Circuit
B0111 44 Open In Side Squib Righthand Circuit
B0112 41 Short To Ground In Side Squib Righthand Circuit
B0113 42 Short To B+ In Side Squib Righthand Circuit
B0115 47 Short In Side Squib Lefthand Circuit
B0116 48 Open In Side Squib Lefthand Circuit
B0117 45 Short To Ground In Side Squib Lefthand Circuit
B0118 46 Short To B+ In Side Squib Lefthand Circuit
B0126 27 Lefthand Seat Belt Buckle Switch Fault
B0127 27 Lefthand Seat Belt Buckle Switch Fault
B0130 63 Short In P/T Squib Righthand Circuit
B0131 64 Open P/T Squib Righthand Circuit
B0132 61 Short To Ground In P/T Squib Righthand Circuit
B0133 62 Short To B+ In P/T Squib Righthand Circuit
B0135 73 Short In P/T Squib Lefthand Circuit
B0136 74 Open P/T Squib Lefthand Circuit
B0137 71 Short To Ground In P/T Squib Lefthand Circuit
B0138 72 Short To B+ In P/T Squib Lefthand Circuit
B1000 31 Air Bag Sensor Assembly Fault
B1100 31 Air Bag Sensor Assembly Fault
B1135 24 Half Connection Detection Fault
B1140 32 Righthand Side Impact Air Bag Sensor Assembly Fault
B1141 33 Lefthand Side Impact Air Bag Assembly Fault
B1142 34 Door Side Impact Air Bag Sensor Righthand Fault
B1143 34 Door Side Impact Air Bag Sensor Righthand Fault
B1144 35 Door Side Impact Air Bag Sensor Lefthand Fault
B1145 35 Door Side Impact Air Bag Sensor Lefthand Fault
B1148 36 Front Air Bag Sensor Righthand Fault
B1149 37 Front Air Bag Sensor Lefthand Fault
B1150 23 Occupant Classification System Fault
B1152 28 Passenger Air Bag ON/OFF Indicator Circuit Fault
B1153 25 Seat Position Sensor Assemble Fault
B1154 38 Air Bag Sensor Rear Righthand Fault
B1155 39 Air Bag Sensor Rear Lefthand Fault
B1156 15 Front Righthand Air Bag Sensor Fault
B1157 15 Front Righthand Air Bag Sensor Fault
B1158 16 Front Lefthand Air Bag Sensor Fault
B1159 16 Front Lefthand Air Bag Sensor Fault
B1160 83 Short In Roof Panel Air Bag Righthand Squib Circuit
B1161 84 Open In Roof Panel Air Bag Righthand Squib Circuit
B1162 81 Short In Roof Panel Air Bag Righthand Circuit To Ground
B1163 82 Short In Roof Panel Air Bag Righthand Circuit To B+
B1165 87 Short In Roof Panel Air Bag Lefthand Squib Circuit
B1166 88 Open In Roof Panel Air Bag Lefthand Squib Circuit
B1167 85 Short In Roof Panel Air Bag Lefthand Circuit To Ground
B1168 86 Short In Roof Panel Air Bag Lefthand Circuit To B+
B1180 17 Short In D Squib 2nd Step Circuit
B1181 18 Open In D Squib 2nd Step Circuit
B1182 19 Short In D Squib 2nd Step Circuit To Ground
B1183 22 Short In D Squib 2nd Step Circuit To B+
B1185 57 Short In P Squib 2nd Step Circuit
B1186 58 Open In P Squib 2nd Step Circuit
B1187 55 Short In P Squib 2nd Step Circuit To Ground
B1188 56 Short In P Squib 2nd Step Circuit To B+
B1602 83 Lost Communication With Front Satellite Sensor Bus Righthand
B1603 83 Righthand Front Satellite Sensor Bus Initialization Incomplete
B1607 84 Lost Communication With Front Satellite Sensor Bus Lefthand
B1608 84 Lefthand Front Satellite Sensor Bus Initialization Incomplete
B1610 13 Righthand Front Air Bag Sensor Circuit Fault
B1612 83 Lost Communication With Righthand Front Air Bag
B1613 83 Righthand Front Air Bag Initialization Incomplete
B1615 14 Lefthand Front Air Bag Sensor Circuit Fault
B1617 84 Lefthand Front Air Bag Sensor Circuit Fault
B1618 84 Lefthand Front Air Bag Initialization Incomplete
B1620 21 Lefthand Side Air Bag Sensor Circuit Fault
B1622 81 Lost Communication With Lefthand Side Air Bag Sensor Assembly
B1623 81 Lefthand Side Air Bag Sensor Assembly Initialization Incomplete
B1625 22 Righthand Side Air Bag Sensor Circuit Fault
B1627 82 Lost Communication With Righthand Side Air Bag Sensor Assembly
B1628 82 Righthand Side Air Bag Sensor Assembly Initialization Incomplete
B1630 23 Lefthand Rear Air Bag Sensor Circuit Fault
B1632 81 Lost Communication With Lefthand Rear Air Bag Sensor
B1633 81 Lefthand Rear Air Bag Sensor Initialization Incomplete
B1635 24 Righthand Rear Air Bag Sensor Circuit Fault
B1637 82 Lost Communication With Righthand Rear Air Bag Sensor
B1638 82 Righthand Rear Air Bag Sensor Initialization Incomplete
B1642 81 Lost Communication With Lefthand Satellite Sensor Bus
B1643 81 Lefthand Satellite Sensor Bus Initialization Incomplete
B1647 82 Lost Communication With Righthand Satellite Sensor Bus
B1648 82 Righthand Satellite Sensor Bus Initialization Incomplete
B1650 32 Occupant Classification System Fault
B1653 35 Seat Position Sensor Assembly Circuit Fault
B1655 37 Lefthand Seat Belt Buckle Switch Assembly Fault
B1660 43 Passenger Air Bag ON/OFF Indicator Light Circuit Fault
B1662 45 Indicator Light Circuit Fault
B1771 Passenger Side Buckle Switch Circuit Fault
B1780 Lefthand Front Occupant Classification Sensor Circuit Fault
B1781 Righthand Front Occupant Classification Sensor Circuit Fault
B1782 Lefthand Rear Occupant Classification Sensor Circuit Fault
B1783 Righthand Rear Occupant Classification Sensor Circuit Fault
B1785 Lefthand Front Occupant Classification Sensor Collision Detection
B1786 Righthand Front Occupant Classification Sensor Collision Detection
B1787 Lefthand Rear Occupant Classification Sensor Collision Detection
B1788 Righthand Rear Occupant Classification Sensor Collision Detection
B1790 Air Bag Assembly Center Communication Sensor Circuit Fault
B1793 Occupant Classification Sensor Power Supply Circuit Fault
B1794 Open In Occupant Classification ECU Battery Positive Live
B1795 Occupant Classification ECU Circuit Fault
B1796 Sleep Operation Failure Of Occupant Classification ECU
B1800 51 Short In D Squib Circuit
B1801 51 Open In D Squib Circuit
B1802 51 Short In D Squib Circuit To Ground
B1803 51 Short In D Squib Circuit To B+
B1805 52 Short In P Squib Circuit
B1806 52 Open In P Squib Circuit
B1807 52 Short In P Squib Circuit To Ground
B1808 52 Short In P Squib Circuit To B+
B1810 53 Short In D Squib Dual Stage – 2nd Step Circuit
B1811 53 Open In D Squib Dual Stage – 2nd Step Circuit
B1812 53 Short In D Squib Dual Stage – 2nd Step Circuit To Ground
B1813 53 Short In D Squib Dual Stage – 2nd Step Circuit To B+
B1815 54 Short In P Squib Dual Stage – 2nd Step Circuit
B1816 54 Open In P Squib Dual Stage – 2nd Step Circuit
B1817 54 Short In P Squib Dual Stage – 2nd Step Circuit To Ground
B1818 54 Short In P Squib Dual Stage – 2nd Step Circuit To B+
B1820 55 Short In Lefthand Side Squib Circuit
B1821 55 Open In Lefthand Side Squib Circuit
B1822 55 Short In Lefthand Side Squib Circuit To Ground
B1823 55 Short In Lefthand Side Squib Circuit To B+
B1825 56 Short In Righthand Side Squib Circuit
B1826 56 Open In Righthand Side Squib Circuit
B1827 56 Short In Righthand Side Squib Circuit To Ground
B1828 56 Short In Righthand Side Squib Circuit To B+
B1830 57 Short In Lefthand Roof Panel Squib Circuit
B1831 57 Open In Lefthand Roof Panel Squib Circuit
B1832 57 Short In Lefthand Roof Panel Squib Circuit To Ground
B1833 57 Short In Lefthand Roof Panel Squib Circuit To B+
B1835 58 Short In Righthand Roof Panel Squib Circuit
B1836 58 Open In Righthand Roof Panel Squib Circuit
B1837 58 Short In Righthand Roof Panel Squib Circuit To Ground
B1838 58 Short In Righthand Roof Panel Squib Circuit To B+
B1860 64 Short In Driver Side Knee Air Bag Squib Circuit
B1861 64 Open In Driver Side Knee Air Bag Squib Circuit
B1862 64 Short To GND In Driver Side Knee Air Bag Squib Circuit
B1863 64 Short To B+ In Driver Side Knee Air Bag Squib Circuit
B1900 73 Short In Lefthand P/T Squib Circuit
B1901 73 Open In Lefthand P/T Squib Circuit
B1902 73 Short In Lefthand P/T Squib Circuit To Ground
B1903 73 Short In Lefthand P/T Squib Circuit To B+
B1905 74 Short In Righthand P/T Squib Circuit
B1906 74 Open In Righthand P/T Squib Circuit
B1907 74 Short In Righthand P/T Squib Circuit To Ground
B1908 74 Short In Righthand P/T Squib Circuit To B+

Suspension 2001 Toyota Hilux 3.0 kzte

 Auto Repair Questions, Toyota  Comments Off on Suspension 2001 Toyota Hilux 3.0 kzte
Jan 292020


Toyota Tacoma

I have a new suspension set from a 2019 Hilux. Can fit on my old 2001 model?



No. The part numbers are completely different and so is the design. With that being said you could make them fit with a set of cutting torches, a welder and a little fabricating.

2001 Toyota Tacoma/Hilux Front Shocks

Model Year Part Number Callout Pricing
SHOCK ABSORBER 10
 All……………………………… 2001-02 4851039585 263.46
 w/o PreRunner…………………….. 2001-04 4851180083 57.73
 w/PreRunner………………………. 2001-04 48510A9080 135.56

2019 Toyota Tacoma/Hilux Front Shocks

Model Year Part Number Callout Pricing
SHOCK ABSORBER 6
Tacoma
 2.7L…………………………….. 2016-19 485108Z359 158.95
 3.5L
  Mark 48510-04190…………………. 2016-19 485108Z253 127.32
  Mark 48510-04200…………………. 2016-19 485108Z359 158.95
  Mark 48510-04220…………………. 2016-19 485108Z360 158.95

Suspension System, Inspection

A visual inspection must always be performed to confirm the presence of aftermarket components, potential collision damage, or areas of concern.

  1. Inspect tire pressures with all normal loads in vehicle and tires cold. Refer to vehicle certification (VT) label.
  2. Verify that all tires are sized to specification. Refer to VT label.
  3. Inspect tires for incorrect wear and damage. Install new tires as required.
  4. Remove any excessive accumulation of mud, dirt, or road deposits from chassis and underbody.
  5. Inspect for aftermarket changes to steering, suspension, and wheel and tire components (such as competition or heavy duty).
  6. Visually inspect components for damage or wear as follows:
    a.Front wheel bearings.
    b.Suspension fasteners.
    c.Springs as well as incorrect spring usage.
    d.Air suspension components, if equipped.
    e.Shock absorbers.
    f.Struts.
    g.Suspension bushings.
    h.Steering system components.
    i.Axle components.
  7. Connect a suitably programmed scan tool to vehicle DLC. Ensure no DTCs are present.
  8. If an obvious cause for an observed or reported condition is found, correct cause as required.
  9. Road test vehicle. Stay alert for any abnormal sounds or vibrations that could originate from suspension system.

Toyota Corolla 2009 Code P0505 Idle Control System

 Auto Repair Questions, Toyota  Comments Off on Toyota Corolla 2009 Code P0505 Idle Control System
Jan 232020


Toyota Corolla

My engine dies on low speed (in hold ups)when the AC is on. I ve already clean the throttle and oxygen sensor, cannot accertain fuel pump pressure, but the car works fine if the AC compressor not ON.



Idle speed can be adjusted but the use of a scan tool is required. One thing to check before you get into that would be to check the PCV Hose connections and condition. Check the the connections and hose for leaks. There is a chance that a Code P0505 – idle control system, may be set in this condition. Check the PCV hose and intake for leaks if code P0505 is set.

Idle Speed Adjustments

Curb Idle Speed

  1. Ensure engine is at operating temperature.
  2. Connect scan tool to DLC.
  3. Turn power switch to ON.
  4. Turn scan tool ON.
  5. Follow scan tool manufacturers instructions.
  6. Idle Speed: 600-700 RPM.

Toyota Code P0505 – Idle Control System

2009-toyota-corolla-code-p0505-1

2009-toyota-corolla-code-p0505-2

Dec 192019


Toyota Tacoma

I replaced the fan clutch this past January because it would squeal really bad for a short while when starting the engine. Now it’s doing it again. Will pulling it apart and adding silicone oil likely fix it, or did I just get a poor after market part, and I need to replace it again?

Basically, my question is can being low on silicon oil cause a fan clutch to squeal? In which case it may be worth trying adding more oil before replacing again.





In most cases the squealing noise is coming from failing serpentine belt. I created the video below to help assist in such an occasion. If you are certain the fan is at fault it doesn’t cost you anything but time to try something before replacing a part. But in my experience if there is a leak, unless you fix the leak, it will still leak.

How to Check your squealing belt



How to Replace Clutch Fan

Removal & Installation

  1. Before servicing the vehicle, refer to the precautions.
  2. Disconnect the negative battery cable.
  3. Remove the engine undercover.
  4. Drain the cooling system.
  5. Remove the 2 bolts and the air pipe, as necessary.
  6. Remove the upper radiator hose from the radiator.
  7. Remove the oil dipstick guide, by removing the bolt.
  8. Remove the power steering drive belt, by loosening the lock bolt and adjusting bolt to the idler pulley, if equipped with power steering.
  9. Remove the No. 2 fan shroud, by removing the 2 clips.
  10. Remove the No. 1 fan shroud, by removing the 4 bolts.
  11. Loosen the idler pulley nut and adjusting bolt and remove the air conditioning drive belt, if equipped with air conditioning.
  12. Remove the alternator drive belt, fan (with fan clutch), water pump pulley and the fan shroud.

◦Stretch the belt and loosen the water pump pulley mounting nuts.

◦Loosen the lock, pivot and the adjusting bolts for the alternator.

◦Remove the alternator drive belt.

◦Remove the 4 water pump pulley mounting nuts.

◦Remove the fan (with fan clutch) and the water pump pulley.

To install:

  1. Installation is the reverse of removal.
  2. Tighten the fan nuts to 16 ft. lbs. (21 Nm).
  3. Fill and bleed the cooling system.
  4. Start the engine and check for leaks.

Power Steering Pump 2004 Toyota Avalon Xl 3.0 L

 Auto Repair Questions, Toyota  Comments Off on Power Steering Pump 2004 Toyota Avalon Xl 3.0 L
Dec 172019


Toyota Avalon

So I’m in the process of fixing my power steering… My mechanic in laws said to replace the pump but every time I put fluid in there it works for a week or so and then the reservoir is empty so I was thinking maybe a leak.. My Question is Would I be better off replacing the whole pump or do I only need to do something else?



You need to locate the leak and repair it. Then fill it with fluid. The power steering is a closed system and should not loose fluid ever. Replace the pump if that is what is leaking.

Power Steering Pump, Replace

  1. Remove righthand front fender apron seal.
  2. Raise and support vehicle, then remove righthand front wheel.
  3. Remove clamp plates and holders, then the clamp from tube.2004-toyota-avalon-power-steering-pump-diagram
  4. Loosen drive belt adjustment bolt, then remove drive belt.
  5. Disconnect oil pressure switch connector.
  6. Remove power steering pump mounting bolts, then the pump with pressure tube attached.
  7. Remove oil pressure switch from union bolt.
  8. Remove union bolt and gasket.
  9. Reverse procedure to install, noting the following:

a. Torque wheel lug nuts to 76 ft. lbs.

b. Torque power steering pump mounting bolts to 32 ft. lbs.

c. Torque power steering pump pressure tubes to 33 ft. lbs.

Gauge fuse keeps blowing 2001 Toyota 4Runner Limited V6

 Auto Repair Questions, Toyota  Comments Off on Gauge fuse keeps blowing 2001 Toyota 4Runner Limited V6
Dec 122019


1999 Toyota 4Runner

The beginning of November my 4runner broke down. We changed the alternator. Well ever since my . Extremely fast almost to the point, you can’t even drive around in it for 10 minutes without it blowing again.

The end of Nov. it went dead on me. So we got a new battery. Once the new battery was in we noticed how the lights inside and out would go real dim when I wasn’t on the gas pedal but as soon as I would push the gas it would brighten back up. Also the same with the air(it’s cold so it’s heat atm). Also, when my alternator went out the first time the gauges and the air cut off, the fuse blew but I didn’t know that at the time.

I’m at a loss on what to do anymore with it. I’ve read everything from a short to the ac compressor but I don’t know what could be wrong. My husband has been trying to fix on it and look things up but he also isn’t a mechanic. But he can normally figure out what’s wrong but we are stuck. Please help. I don’t want to get rid of it but if I have to I will.



Gauge fuse keeps blowing

Looking at the wiring diagram in reference to the alternator and gauges I see a DIODE between the IGN fuse and the alternator. If anyone of the wires in the wiring harness are shorted or the diode has failed it may cause this issue. Checking the wiring in the wiring harness would be a good first step.

Unplug the connectors and check for continuity from the blown 10 amp Gauge fuse to ground. Then Isolate the connections and test the wires to each other to find the short.

How to Use a Multimeter

It may be internal in the alternator. I will just say that if you have replaced it with a REMANUFACTURED(REMAN) alternator there is a good chance the alternator is bad again.

2001 Toyota $ Runner Charging System Wiring Diagram

Splash Shield making Knocking Noise when Driving straight

 Auto Repair Questions, Toyota  Comments Off on Splash Shield making Knocking Noise when Driving straight
Dec 102019


Toyota Camry

I have 2007 Camry, it is making knocking sound when I go over 80Kmph(50mph) from the right front side. No sound while turning, only when driving straight at high speed. What could be possible problem?



I would guess an air damn/splash shield or piece of trim has come loose. Damage can occur easily if driven over a parking block, etc. Make sure to check the Right Front Fender Splash Shield and Wheel Opening Extension Pad.

2007-toyota-camry-wheel-opening-extension-pad

How to check your Splash Shield
